Air cooling Fiber laser welder PT26-A07 Series

Compact, portable, no water required, ideal for field & intermittent welding. Suitable for processing carbon steel, copper alloy, aluminum alloy, galvanized sheet, stainless steel, gold-plated sheet, and silver-plated sheet materials....

Send Inquiry

Air-Cooled
Laser Welder

Lightweight. Maximum Power.

The PT26 SERIES handheld laser welding with its innovative air-cooled design. No external chiller needed — built-in air cooling delivers reliable performance in a portable package. Precise welds, clean finish, engineered for industry.

Technical Specifications

Parameter	Value
Model	PT26-A
Laser Source	Raycus Fiber Laser
Wavelength	1064nm
Laser Power Options	1000W / 1200W / 1500W / 2000W
Cooling Method	Air-Cooled (No chiller needed)
Electro-Optical Efficiency	30%+
Laser Diode Lifespan	100,000 hours
Ingress Protection	IP65
Operating Temperature	-10 ~ 40°C
Welding Gun	Handheld (ergonomic design)
Wire Feeder	Automatic (0.8-1.6mm)
Fiber Length	10m (customizable)
Power Supply	220V / 50Hz / 60Hz
Continuous Operation	7×24h
System Stability Rate	99.9%
Response Time	0.1s

Key Highlights

Raycus Fiber Laser Source

Trusted Chinese laser brand. 100,000+ hours diode lifespan, 30%+ electro-optical efficiency. High beam quality for stable, consistent welding.

Air-Cooled for Reliability

No external chiller needed. Built-in air cooling system. IP65 protection rating. Operates in -10~40°C environments.

Precise Welds. Clean Finish.

Minimal heat affected zone, no discoloration, smooth and clean weld seam. 3-5x faster than TIG welding.

Auto Wire Feeder

Integrated automatic wire feeding system. Supports 0.8-1.6mm wire diameters for versatile welding applications.

Intelligent Monitoring System

Real-time temperature monitoring, fault alarm with error codes, safety interlock, and welding parameter data recording.

Portable & Lightweight

Compact design with caster wheels and carry handles. One person can move it. Setup in 5 minutes.

Air-Cooled vs Water-Cooled

See why air-cooled is the future of handheld laser welding

Feature	PT-26 Air-Cooled	Traditional Water-Cooled
Cooling System	Air-Cooled (Built-in)	Water Chiller Required
Protection Rating	IP65	IP54 or lower
Power Consumption	Low (no chiller)	High (chiller + laser)
Portability	Caster wheels, carry handles	Heavy, requires forklift
Maintenance	Minimal, no water change	Regular water & filter change
Operating Temp	-10 ~ 40°C	5 ~ 35°C (chiller limit)
Setup Time	5 minutes	30+ minutes
Outdoor Use	Yes	Limited (freezing risk)

Get a customized quote with your specific requirements. Our engineers will help you choose the suitable model!
